PVC Premium Electrical Adhesive Tap-21156


Lixin 21156 is a 0.15mm premium quality, electrical self-extinguishing soft PVC tape which uses an aggressive pressure sensitive rubber-based adhesive system. It has been designed for use where a recognised specification or international standard is required and where environmental safety is of concern.




PVC Premium Electrical Adhesive Tape - 0.15mm

PRODUCT REFERENCE

Lixin 21156 is a 0.15mm premium quality, electrical self-extinguishing soft PVC tape which uses an aggressive pressure sensitive rubber-based adhesive system. It has been designed for use where a recognised specification or international standard is required and where environmental safety is of concern.





Colours

Black, Red, Blue, Yellow, Brown, Orange, Violet, Yellow/Green, Blue transparent, Grey



Adhesive

Rubber Resin


Carrier

Soft PVC



Thickness

0.15 mm


APPLICATIONS
·Primary electrical insulation
·Harnessing
·Protection for low and medium voltage cables splices
·Colour coding
·Industrial applications


PRODUCT BENEFITS
·Excellent resistance to abrasion, corrosion and moisture
·High dielectric strength and mechanical protection
·Excellent conformability
·Tape can be applied at low temperature (till -10°C)
·Conforms to the European Directive 2011/65/EC (RoHS 2) and Commission Delegated Directive (EU) 2015/863 (RoHS 3)
·Index temperature 0°C to 90°C
Features
·Flame Retardant
·Self-extinguishing
·Easy unwind and easy tear
·Flexible and Conformable
·Water Resistant
·UV Resistant
·Abrasion Resistant
·Non-corrosive adhesive







product Total  Thickness Carrier Backing Thickness Adhesion to steel Adhesion to Backing Tensile Strength
Elongation
(%)
Dielectric Strength  Max.Continuous Operating Temperature
(um) (um) N/cm N/cm N/cm % kv/mm
21116 110 PVC Flim 95 1.2 1.0  18 220 45 80°C/176°F
21126 120 PVC Flim 105 1.2 1.0  19 220 45 80°C/176°F
21G66 130 PVC Flim 115 1.2 1.0  21 230 45 80°C/176°F
21156 150 PVC Flim 135 1.2 1.0  23 250 45 80°C/176°F
21166 165 PVC Flim 150 1.2 1.0  25 250 43 80°C/176°F
21176 175 PVC Flim 160 1.2 1.0  27 250 43 80°C/176°F
21556 180 PVC Flim 165 1.2 1.0  28 250 43 80°C/176°F
21196 190 PVC Flim 175 1.2 1.0  29 250 43 80°C/176°F
21206 200 PVC Flim 185 1.2 1.0  30 250 43 80°C/176°F
